FEATURE

● 100 to 240 VAC universal input
● Built-in EMI filter
● High efficiency
● 100% burn-in
● Input surge current protection
● Over voltage protection
● Over current protection
● Meets UL cUL TUV safety standards

ENVIRONMENTAL

● Dimension: L63*W60*H24.5mm
● Operating Temperature: 0 ~ +40℃
● Operating Humidity: 20 ~ 85%
● Storage Temperature: - 40 ~ +70℃
● Storage Humidity: 10 ~ 95%

● Input voltage: 100 to 240 VAC
● Input frequency: 47 to 63 Hz single phase
● Input current: 1.2A (rms) for 115 VAC
                          0.6A (rms) for 230 VAC

● Output spec:
When TYPE-C port is used alone, the maximum support of
TYPE-C port is 45 W(5V3A,9V3A,12V3A,15V3A, 20V3A).
When TYPE-C port is used together with USBA port, TYPE-C
port supports a maximum of 30W(5V3A,9V3A,12V2.53A,
15V2A, 20V1.5A) ; USBA port supports a maximum of 18W
(5V3A,9V2A,12V1.5A).
●Supported protocol:
TYPE-C port supports PD3.0,QC2.0, QC3.0, Apple Mode and
BC1.2 protocols ; USBA port supports QC2.0,QC3.0,BC1.2 and Apple Mode protocols.
● Ripple and noise: 150mV P-P max.
● Over voltage protection: 110 to 120% output(Auto Recovery)
● Over current protection Over power protection:
100 to 120% of rated power.
● Line regulation: ±1% (entire operation range) .
● Load regulation: ±5% (main load to full load) .
